LC-7057 convection cooling test device

Use: For EN 511, GB / T 38304-2019 to measure the degree of cold gloves to withstand cold convection (convective heat resistance value-the ability of the glove to resist heat loss of the hand) test.

Standard: EN 511, GB / T 38304-2019;

characteristic:

The system includes: hand model, climate room, acquisition device and test software

Standard porcelain hand model, dimensions to EN 511 standard, made of carbon composite with a heating element inside to provide uniform surface temperature to simulate the surface of the human hand.

The model has two measurement areas-the hand and forearm, separated by a reserve at the wrist. Both zones were heated to the same temperature and the temperature loss was recorded for each area separately to provide data for measurement of glove effectiveness.

Standard test software, automatic or manual test operation

The hand heating system can maintain a stable heat flow of 200 W/m2 through the hand die

The surface temperature of hand mold shall not be less than 30~35℃, and the local deviation of surface temperature shall not exceed ± 1℃

Customized ambient climate chamber temperature, humidity deviation, airflow velocity, turbulence intensity are within the standard tolerance

Size (length * width * height cm): 120 * 50 * 70

Weight (kg): 200

Installation requirements:

1、 Power supply: AC 220V 50Hz 2500W

2、 Environment: 23 ± 2℃

3、 Operation: experimental table

configure:

1、 Hand model 1;

2、 Climate room 1;

3、 1 copy of the standard test software;

4、 A set of computer

5. Operation instructions

6. One third-party measurement and calibration report
